At Band-Optics Technology, we excel in manufacturing high-precision optical windows that serve as critical components in various optical systems. Our optical windows are crafted utilizing premium materials like Schott, CDGM, Ohara, Hoya, Corning glasses, along with specialized infrared materials such as Sapphire, Germanium, Silicon, Sodium Chloride, Magnesium Fluoride, Zinc Selenide, and Zinc Sulphide. These windows are essential for applications ranging from precision laser systems to rugged environmental monitoring equipment, ensuring optical clarity and durability in demanding conditions.
Superior Optical Quality: Our windows are polished to achieve exceptional flatness with tolerances of PV<1/40λ and RMS<1/100λ, ensuring minimal optical distortion and maximum transmission efficiency.
Wide Material Selection: We offer an extensive array of materials to accommodate different wavelength ranges and application-specific requirements, from visible light to infrared spectra.
Customizable Specifications: We provide customization services for dimensions, coatings, and tolerances to meet the precise needs of your optical system design.
Robust Durability: Engineered to withstand harsh environmental conditions, our windows feature high resistance to scratches, thermal fluctuations, and environmental degradation, ensuring long-term performance and reliability.
| Parameter | Standard Windows | Customizable Options |
|---|---|---|
| Material | Schott, CDGM, Ohara, Hoya, Corning glasses; IR materials like Sapphire, Germanium, Si, ZnSe, ZnS, etc. | Extensive range of optical and infrared materials |
| Dimensions | 1-1050mm +/-0.05mm | Custom sizes up to 1050mm |
| Thickness | 0.2-100mm +/-0.01mm | Custom thickness available |
| Flatness | PV<1/40λ, RMS<1/100λ | Premium flatness specifications achievable |
| Surface Quality | 20-10 or 10-5 | Custom surface quality options |
| Coating | AR coated single/both sides (R<0.1%) | Various coatings including HR, NPBS, BS, etc. |
Our optical windows find utility across multiple sectors:
Laser Technology: Integral to spectroscopy equipment, laser surgical devices, and precision welding systems for unparalleled optical performance.
Defense & Aerospace: Utilized in surveillance systems, targeting mechanisms, and satellite-mounted optical instruments for superior imaging quality.
Engineering & Manufacturing: Vital for laser cutting machines, infrared temperature sensors, and process monitoring systems to ensure precision and reliability.
Biotechnology: Employed in blood analysis equipment, fluorescence microscopes, and cell sorting systems for accurate biological assessments.
Oil & Gas: Critical for infrared detection systems, environmental monitoring gear, and gas analysis instruments to enhance safety and efficiency.
Selecting the appropriate optical window involves several key considerations:
Material Choice: Based on the wavelength range of your application and environmental factors such as temperature and chemical exposure.
Dimensional Requirements: Determined by the physical space constraints and optical design of your system.
Optical Performance Needs: Including desired flatness, parallelism, and surface quality to meet specific optical functionality demands.
Environmental Considerations: Assessing factors like potential exposure to moisture, dust, and temperature extremes to ensure window durability.
Band-Optics Technology is a trusted name in the optical components industry, holding ISO 9001:2015 certification as a testament to our unwavering commitment to quality and customer satisfaction. With over 15 years of experience, we have established strong partnerships with clients across industries such as medical technology, defense, aerospace, and scientific research. Our state-of-the-art manufacturing facilities and rigorous quality control protocols ensure that each optical window meets the highest standards of precision and reliability.
Q: Can your windows be customized for specific optical systems?
A: Absolutely. We specialize in custom optical window solutions tailored to meet the exact specifications and requirements of your unique optical system. Whether it’s a specific material, size, coating, or tolerance, we can accommodate your needs.
Q: What coatings are available for your optical windows?
A: We offer a variety of coatings, including anti-reflective (AR), high-reflective (HR), non-polarizing beam splitters (NPBS), beam splitters (BS), longpass dichroic (LP), shortpass dichroic (SP), and more, to enhance the optical performance of our windows in different applications.
Q: How do you ensure the quality and consistency of your products?
A: Our quality assurance process involves multiple stages of inspection and testing using advanced metrology equipment. We adhere to strict manufacturing standards and continuously monitor our processes to ensure each window meets our high-quality benchmarks.
Q: What industries commonly use your optical windows?
A: Our optical windows are widely used across numerous industries, including laser technology, defense & aerospace, engineering & manufacturing, biotechnology, oil & gas, and scientific research. They play crucial roles in applications such as laser systems, surveillance equipment, medical diagnostic instruments, and environmental monitoring devices.
