Band-Optics Technology specializes in manufacturing high-precision optics prisms that deliver superior performance for a wide range of applications. Our extensive product line includes right angle prisms, equilateral prisms, porro prisms, dove prisms, amici prisms, wedge prisms, rhomboid prisms, penta prisms, pellin-Broca prisms, littrow prisms, anamorphic prism pairs, corner cube prisms, polygon prisms, Fresnel prisms, and inverting prisms. These prisms are carefully crafted using premium materials such as Schott, CDGM, Ohara, Hoya, Corning glasses, and specialized infrared materials like Sapphire, Germanium, and Silicon. Our prisms are designed to meet the demanding requirements of industries such as laser technology, defense, aerospace, engineering, manufacturing, and biotechnology.
Precision Optics: Our prisms are manufactured with exceptional precision, ensuring minimal light loss and optimal performance in optical systems.
Diverse Types: We offer a wide array of prism types to suit various application-specific requirements.
High-Quality Materials: Utilizing premium materials to ensure superior performance and durability in different environments.
Customization: We provide custom solutions tailored to specific customer requirements, including specialized coatings and dimensional specifications.
Rigorous Quality Control: Our stringent quality assurance processes guarantee consistent performance and reliability, meeting the highest industry standards.
| Parameter | Materials | Dimensions | Surface Quality | Angular Tolerance | Coating Options |
|---|---|---|---|---|---|
| Right Angle Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Equilateral Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Porro Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Dove Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Amici Prisms | Schott, CDGM, Ohara, Hoya, Corning | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Wedge Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Rhomboid Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Penta Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Pellin-Broca Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Littrow Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Anamorphic Prism Pairs | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Corner Cube Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Polygon Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Fresnel Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
| Inverting Prisms | Schott, CDGM, Ohara, Hoya, Corning; IR materials like Sapphire, Germanium, Silicon | 2-300mm +/-0.25mm | 20-10 or 10-5 | <2 arc seconds | AR coated, blackened, mirror coated |
Optics prisms are widely used in various fields:
Laser Technology: Ideal for beam steering, laser scanning systems, and laser material processing.
Defense & Aerospace: Utilized in surveillance systems, targeting systems, and satellite optical systems.
Engineering & Manufacturing: Vital for optical measurement systems, alignment systems, and process control systems.
Biotechnology: Employed in medical imaging equipment, fluorescence microscopes, and bio-analysis instruments.
Research & Development: Applied in scientific research for experiments requiring precise light reflection, refraction, and dispersion.
Selecting the appropriate optics prism involves several key considerations:
Application Requirements: Determine the specific requirements of your application, such as light deviation, dispersion, or beam steering.
Material Selection: Choose a material that suits your application’s wavelength range and environmental conditions.
Dimensional Specifications: Match the physical dimensions to your system’s design and space constraints.
Coating Needs: Select coatings that enhance the prism’s performance in your specific application.
Band-Optics Technology is a trusted name in the optical components industry, holding ISO 9001:2015 certification. Our commitment to quality and customer satisfaction has been recognized through this certification. With over 15 years of experience, we have established strong partnerships with clients across various industries. Our state-of-the-art manufacturing facilities and rigorous quality control protocols ensure that each optics prism meets the highest standards of precision and reliability.
Q: Can your optics prisms be customized for specific optical systems?
A: Yes, we specialize in custom optics prism solutions tailored to meet the exact specifications and requirements of your unique optical system.
Q: What materials are available for your optics prisms?
A: We offer a wide range of materials, including Schott, CDGM, Ohara, Hoya, Corning glasses, and specialized infrared materials such as Sapphire, Germanium, and Silicon.
Q: How do you ensure the quality and consistency of your optics prisms?
A: Our quality assurance process involves multiple stages of inspection and testing using advanced metrology equipment. We adhere to strict manufacturing standards and continuously monitor our processes to ensure each prism meets our high-quality benchmarks.
Q: What industries commonly use your optics prisms?
A: Our optics prisms are widely used across numerous industries, including laser technology, defense & aerospace, engineering & manufacturing, biotechnology, and scientific research.
